Model: SPAWM-24Ab/32Ab/48Aa/64Aa
Pipe Diameter Applicable: DN400/DN600/DN800/DN1200/DN1600
Advantage:
Performance Features: A patented product, The first choice for heavy wall thickness pipe fabrication production line, significantly increasingflow-process performance;separate welddriving system and column/boom system; weld driving system can move along the track; standard configuration: Lincoln Flextech650 multi-function welding power; TIG/MIG root welding with QSPT's root welding technology; TIG/MIG/SAW fill-in and cap welding;operation through a streamline welding control cabinet + an aluminum alloy wire control.
Original split design
Easier load and unload
Pipe automatic welding master
Rotator drive, rotator press down, telescopic boom welding
Super torque: 13200N.m
Standard configuration: Lincoln Flextech650
TIG/MIG/ SAW
Max. DN1600
Max. 60mm
Max. 600DI/D（MIG+ SAW）
Max. equivalent to 12 welders
Production line equipment
High efficiency and safety
